Frameset
Frame Aluminium, Smooth Welding, 12x148mm Boost, Tapered HT
Fork X-fusion RC32 Air, 130mm, 15x110mm Boost
Drivetrain
Rear Shifter Shimano Deore SL-M6200-R, 12spd
Rear Derailleur Shimano Deore RD-M6200, SGS, 12spd
Crankset Prowheel Alloy, 30T, 170mm (S-M), 175mm (L - XXL)
Bottom Bracket Prowheel Cartridge
Cassette Shimano Deore CS-M6200-12, 10-51T, 12sp
Chain KMC 12spd
Brakes
Front Brake Shimano Deore BR-MT200, Resin pads
Front Brake Rotor Shimano SM-RT26, 160mm, 6-bolt
Rear Brake Shimano Deore BR-MT200, Resin pads
Rear Brake Rotor Shimano SM-RT26, 160mm, 6-bolt
Brake Levers Shimano Deore BL-MT200
Components
Handlebar Norco Aluminium, 760mm (S), 780mm (M,L,XL, XXL) 30mm Rise
Stem Alloy 40mm Length, 31.8mm Clamp
Seatpost X-Fusion Manic LC, 31.6mm, 130mm (S), 150mm (M), 170mm (L/XL/XXL)
Headset Sealed Cartridge Bearings, Tapered 1-1/8" - 1.5" ( IS42/28.6 | IS52/40 )
Headset Spacer 3x10mm
Saddle Norco XC, Steel Rail
Grips Norco lock-On, 130mm length
Pedals Nylon Flat Pedal, Chromoly Axle
Seatpost Clamp Norco Alloy QR, 34.9mm ID
Wheels
Front Hub KT Sealed Bearing, 15x110mm Boost, 32h, 6-bolt
Rear Hub KT,12x148mm Boost, MS, 32h, 6-bolt
Rims Alloy XD-155, 32H
Front Tire Maxxis Forekaster, 29x2.4" (27.5X2.25"size S), Wire
Rear Tire Maxxis Forekaster, 29x2.4" (27.5X2.25"size S), Wire
Spokes/Nipples Stainless Steel, 14g
