Frameset
Frame Aluminium, 9x135mm QR, 20"
Fork SR Suntour XCR Air w/LO, 63mm, 9X100 QR
Drivetrain
Rear Shifter Shimano Altus SL-M315-8R, 8sp, Rapid Fire plus
Rear Derailleur Shimano Acera RD-M3020-8, 8sp, SGS
Crankset Alloy 3pc, 140mm, 28T Narrow Wide
Bottom Bracket Sealed bearing, ST 68mm
Cassette Shimano Altus CS-HG31, 11-30T, 8sp
Chain KMC Z9
Brakes
Front Brake Tektro HD-M286, Resin Pads
Front Brake Rotor Tektro. 160mm rotor, 6-bolt
Rear Brake Tektro HD-M286, Resin Pads
Rear Brake Rotor Tektro. 160mm rotor, 6-bolt
Brake Levers Tektro HD-M286, Hydraulic 2-Finger Jr. Levers
Components
Handlebar Alloy Jr. Riser, 540mm, 30mm Rise
Stem Alloy 35mm Length, 31.8mm Clamp
Seatpost Norco Alloy 27.2mm, 250mm length
Headset External Cup Ball Bearing, 1-1/8" EC 34
Headset Spacer 1x10mm , 2x5mm
Saddle Norco Youth, Steel Rail
Grips Norco Youth, 115mm Length
Pedals Jr. MTB Flat, 9/16"
Seatpost Clamp Norco Alloy Bolted, 31.8mm ID
Wheels
Front Hub Formula DC-1420 , 9x100mm QR, 28h, 6-bolt
Rear Hub Formula DC-1425,10x135mm QR, HG, 28H, 6-bolt
Rims Aluminium DW, 28h, 20" MTB
Front Tire CY Trail, 20x2.25", Wire
Rear Tire CY Trail, 20x2.25", Wire
Spokes/Nipples Stainless Steel w/Brass Nipples - Black
Weight
Weight 10.63 kg (23.4 lbs)
